LM386 IC -Low Voltage Audio Power Amplifier DIP-8 Package

LM386 IC -Low Voltage Audio Power Amplifier DIP-8 Package

The LM386L-1 and LM386MX-1 are power amplifiers designed for use in low-voltage consumer applications. The gain is internally set to 20 to keep the external part count low, but the addition of an external resistor and capacitor between pins 1 and 8 will increase the gain to any value from 20 to 200. The inputs are ground referenced while the output automatically biases to one-half the supply voltage.

Features/Specs:

• Part No: LM386L
• Manufacturer: UNISONIC TECHNOLOGIES CO., LTD
• Battery Operation
• Minimum External Parts
• Wide Supply Voltage Range: 4 V–12 V
• Low Quiescent Current Drain: 4 mA
• Voltage Gains from 20 to 200
• Ground-Referenced Input: Self-Centering Output Quiescent Voltage
• Low Distortion: 0.2% (AV = 20, VS = 6 V, RL = 8 Ω, PO = 125 mW, f = 1 kHz)
• Mounting Type: Through Hole
• Package / Case: 8-DIP (0.300″, 7.62mm)

Datasheet: LM386

Package Includes:

• 1 x LM386 IC -Low Voltage Audio Power Amplifier DIP-8 Package

Note: Product Images are shown for illustrative purposes only and may differ from the actual product.
