TTP224 4-way Capacitive Touch Switch Module

70.00 (Incl. Tax)

5 in stock

1 People watching this product now!
Description

This is a 4 switch digital touch sensor
with capacitive sense technology, the TTP 224 IC offers capacitive sense
input feed designed for touchpad control, followed by a 4- finger-sized
touchpad. The board has a jumper’s arrangement to change the keypress
output mode in Timed or Toggle, Active High or Active Low. Separate
jumper adjustments are provided for changing the response time of the
pressed key: 60mS fast mode or 160mS in Low power. The output side of
the board has 6 pin headers, with 4 pins to be connected with the
digital I/O of any microcontroller board (Arduino, ARM STM32). 4 status
LED SMD types are provided to check the status of each pressed key. TTP
224 4 Channel Digital Touch Sensor is compatible with all Arduino’s
board. The board finds applications in HMI(Human-machine Interface),
mechanical Button key replacement.


Features:

  1. TTP224 4-way switch digital touch capacitive touch sensor module
  2. 4 keyboard TTP224 capacitive touch sensor IC
  3. Onboard 4-level status indicator
