3S 10A 12V 18650 Lithium Battery Charger Board Protection Module BMS

In 3S 10A 12V 18650 Lithium Battery
Charger Board Protection Module, 3S stands for 3 18650 batteries or
polymer lithium battery series combination. With 10.8V rated voltage for
polymer battery, 11.1V 18650 or 3.7V lithium battery rated voltage and
12.6V lithium battery can be charged. And discharge 10A (referring to
the maximum discharge current limit) Lithium battery protection board it
also Comes with over-charge, over-discharge, over-current, short
circuit protection.

formula expansion :

1C battery expansion, 2000 capacity is equal to 2AH * 1 = 2A upper limit of current.
3C battery expansion, 2000 capacity equal to 2AH * 3 = 6A upper operating current.

If
the battery gets heat, does not apply that battery, such a situation
cannot be long-term use, the battery will soon be damaged.

Notes :

1: strictly according to the drawing wiring 0 V (B), 3.7 V (B1), 7.4 V (B2), 11.1 V (B +), not intentionally short circuit!
2: Once you have charged the first line, it will have output.
3: When connecting three battery groups, please make sure that the
voltage of each battery group, if not the same, fill each battery
separately and then use it in series. discharge test, the fastest
battery voltage drop, which group is low battery. (2 good battery + a
use effect = 3 low battery low battery use effect).

Warning:

The
protection board can not be used for lithium iron phosphate batteries,
lamp hernia, hand drill battery, electric battery fish, electric bicycle
battery, car battery for children, 775 (4A) motor, 1 W fish eye LED
light, please pay attention customer purchase connection! Described in
terms of power for the following products: Massager rechargeable
battery, LED ready light power supply, 12 V electronic products, solar
street lamp battery, power backup monitor, and other products.

Connection Diagram:

Features :

1. Operating current : 6 – 8A.
2. Current limit : 10 – 13A.
3. Storage condition : -40 ~ +80 ℃.
4. Resting current: less than 30uA.
5. Effective lifetime: over 30,000 hours.
6. Internal resistance: less than 100mΩ.
7. Short-circuit protection: protection.
8. Self-recovery delay.

Package Includes :

1 x 3S 10A 12V 18650 Lithium Battery Charger Board Protection Module.

No Guarantee No Warranty

Actual product may vary from the product photograph displayed above. Photograph just for reference.
