MSP-EXP430FR6989 Development Board MSP430FR6989 FRAM Launchpad Segmented LCD Display Energy Trace++ Technology
The
MSP-EXP430FR6989 LaunchPad Development Kit is an easy-to-use Evaluation
Module (EVM) for the MSP40FR6989 microcontroller (MCU). It contains
everything needed to start developing on the ultra-low-power MSP430FRx
FRAM microcontroller platform, including on-board emulation for
programming, debugging and energy measurements. The board features
on-board buttons and LEDs for quick integration of a simple user
interface as well as a Liquid Crystal Display (LCD) display which
showcases the integrated driver that can drive up to 320 segments. It
also offers direct access to the Extended Scan Interface, which is a
dual analog front-end (AFE) created for low-power rotation detection.
The MSP430FR6989 device features ultra-low power consumption, 128 KB of
embedded FRAM (Ferroelectric Random Access Memory), a non-volatile
memory known for its ultra-low power, high endurance and high speed
write access.
MSP-EXP430FR6989 LaunchPad Development Kit is an easy-to-use Evaluation
Module (EVM) for the MSP40FR6989 microcontroller (MCU). It contains
everything needed to start developing on the ultra-low-power MSP430FRx
FRAM microcontroller platform, including on-board emulation for
programming, debugging and energy measurements. The board features
on-board buttons and LEDs for quick integration of a simple user
interface as well as a Liquid Crystal Display (LCD) display which
showcases the integrated driver that can drive up to 320 segments. It
also offers direct access to the Extended Scan Interface, which is a
dual analog front-end (AFE) created for low-power rotation detection.
The MSP430FR6989 device features ultra-low power consumption, 128 KB of
embedded FRAM (Ferroelectric Random Access Memory), a non-volatile
memory known for its ultra-low power, high endurance and high speed
write access.
- EnergyTrace Technology for ultra-low-power debugging
- 40 pin LaunchPad standard leveraging the BoosterPack ecosystem
- 128 KB FRAM
- 100 uA/MHz active mode and 350 nA standby with RTC and 3.7 pF crystal
- Certified ULPBench score of 109
- 16-Bit RISC architecture up to 8-MHz FRAM access/ 16MHz system clock speed
- Onboard eZ-FET emulation
- 2 buttons and 2 LEDs for User Interaction
- 320-segment LCD controller
- 83 GPIO
