74HC151 8-Input Multiplexer IC (74151 IC)

74HC151 is 8 – Input Multiplexer 16 Pin IC. Data Selector/Multiplexer contains full on-chip decoding to select one-of-eight data sources as a result of a unique three binary code at select inputs. Two complementary outputs provide both inverting and non-inverting buffer operation. A Strobe input is provided which, when at  high level, disables all data inputs and forces Y output to low state and W output to high state. Select input buffers incorporate internal overlap features to ensure that select input changes do not cause invalid output transients.Used for Boolean Function Generator.

Features:-

• Advanced oxide-isolated, ion-implanted Schottky TTL process
• Switching performance is guaranteed over full temperature and VCC supply range
• Pin and functional compatible with LS family counterpart
• Improved output transient handling capability

Specifications:-

• Type: CMOS
• Voltage Rating: 5VDC
• Temperature Rating: -65 to 165 Deg C
• Mounting: Through Hole
